SABS 1123 2500/3 PL平板法兰标准

PN

DN

D

k

H

No.

C

T

A

F

KG

KG

Nominal pressure 2500 kPa

10

90

60

14

4

17.2

12

40

2

0.61

0.54

15

95

65

14

4

21.3

14

45

2

0.77

0.69

20

105

75

14

4

26.9

14

58

2

0.94

0.85

25

115

85

14

4

33.7

16

68

2

1.26

1.16

32

140

100

18

4

42.4

18

78

2

2.04

1.89

40

150

110

18

4

48.3

20

88

3

2.68

2.43

50

165

125

18

4

60.3

20

102

3

3.16

2.88

65

185

145

18

8

76.1

22

122

3

3.99

3.68

80

200

160

18

8

88.9

22

138

3

4.55

4.21

100

235

190

22

8

114.3

25

162

3

6.61

6.15

125

270

220

26

8

139.7

28

188

3

9.18

8.58

150

300

250

26

8

168.3

30

218

3

11.46

10.77

175

330

280

26

12

193.7

30

248

3

12.88

12.15

200

360

310

26

12

219.1

30

278

3

14.96

14.14

*225

395

340

26

12

244.5

30

306

3

17.94

16.94

250

425

370

26

12

273

30

335

3

19.95

18.83

300

485

430

26

16

323.9

32

395

4

26.54

24.86

350

555

490

33

16

355.6

35

450

4

39.50

37.32

400

620

550

33

16

406.5

40

505

4

54.77

52.00

450

670

600

33

20

457.2

45

555

4

65.93

63.00

500

730

660

33

20

508

50

615

4

84.31

81.03

550

785

710

39

20

559

55

670

5

101.18

96.96

600

845

770

39

20

609.6

60

720

5

125.12

120.03
