PN

DN

D

k

H

No.

C

T

A

F

KG

KG

Nominal pressure 1600 kPa

10

90

60

14

4

17.2

10

40

2

0.52

0.45

15

95

65

14

4

21.3

10

45

2

0.58

0.50

20

105

75

14

4

26.9

10

58

2

0.70

0.62

25

115

85

14

4

33.7

10

68

2

0.84

0.74

32

140

100

18

4

42.4

10

78

2

1.22

1.07

40

150

110

18

4

48.3

10

88

3

1.51

1.26

50

165

125

18

4

60.3

12

102

3

2.06

1.78

65

185

145

18

4

76.1

12

122

3

2.51

2.18

80

200

160

18

8

88.9

14

138

3

3.09

2.75

100

220

180

18

8

114.3

14

158

3

3.43

3.05

125

250

210

18

8

139.7

16

188

3

4.74

4.28

150

285

240

22

8

168.3

18

212

3

6.35

5.75

175

315

270

22

8

193.7

20

242

3

8.21

7.53

200

340

295

22

12

219.1

22

268

3

9.53

8.83

*225

370

325

22

12

244.5

22

294

3

11.00

10.17

250

405

355

26

12

273

25

320

3

14.06

13.07

300

460

410

26

12

323.9

28

378

4

19.46

17.97

350

520

470

26

16

355.6

30

438

4

27.93

26.26

400

580

525

26

16

406.4

35

490

4

38.60

36.49

450

640

585

26

20

457.2

40

550

4

50.78

48.47

500

715

650

33

20

508

40

610

4

62.82

59.92

600

840

770

33

20

609.6

50

725

5

105.95

101.07
